Product Description
Engineered with Komatsu's proven 3D68E-N3FB engine delivering 12.7kW at 2600rpm, this 2016 PC15R-8 mini excavator represents precision Japanese manufacturing adapted for demanding jobsite conditions. Operating at just 1,650kg working weight with exceptional 29.6kPa ground pressure distribution, this compact machine accesses confined urban environments without compromising structural integrity or performance output.
Technical specifications demonstrate superior engineering:
- Maximum digging depth of 2,160mm with 3,640mm excavation radius
- 23-liter hydraulic system capacity ensuring consistent operational pressure
- Zero tail swing design with 1,070mm rear turning radius for tight-quarter maneuverability
- Dual bucket configuration: 0.04m³ standard / 0.02m³ precision trenching
- Compact transport dimensions: 3,745mm length × 1,000mm width
Currently located in Shenzhen, Guangdong, this joint-venture manufactured unit maintains Komatsu's reputation for hydraulic efficiency and component longevity. The 0.78L displacement engine operates within optimized fuel consumption parameters while the reinforced undercarriage withstands continuous loading cycles. Ideal for utility inst
| Specifications | Value |
|---|---|
| No. | 1032318 |
| Tonnage (tons) | 1 |
| Working weight (kg) | 1650 |
| Bucket capacity (m³) | 0.04/0.02 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu Komatsu 3D68E-N3FB |
| Rated power (kw/rpm) | 12.7/2600 |
| Displacement (L) | 0.78 |
| Ground specific pressure (Kpa) | 29.6 |
| Travel speed (km/h) | 4.2 |
| Fuel Tank (L) | 20 |
| Engine Oil changes (L) | 2.8 |
| Coolant (L) | 3.2 |
| Hydraulic System (L) | 23 |
| Total transport length (mm) | 3745 |
| Total transport width (mm) | 1000 |
| Total transport height (mm) | 2229 |
| Full cab height (mm) | 2229 |
| Counterweight ground clearance (mm) | 437 |
| Back end turning radius (mm) | 1070 |
| Track gauge (mm) | 770 |
| Track plate width (mm) | 230 |
| Track ground length (mm) | 1015 |
| Maximum digging depth (mm) | 2160 |
| Maximum excavation height (mm) | 3480 |
| Maximum unloading height (mm) | 2500 |
| Maximum vertical digging depth (mm) | 1560 |
| Maximum excavation radius of stop surface (mm) | 3640 |
