Product Description
Discover the 2020 Komatsu PC160-7, a prime example of reliable and robust construction machinery. Located in Guangdong, China, this excavator is ready to meet your project demands with its well-maintained condition. Equipped with an original air conditioning system, it ensures operator comfort even in challenging environments. The machine has undergone a comprehensive major service, ensuring that it is fully prepared to be deployed directly to your worksite without any additional maintenance required.
- Year: 2020
- Brand: Komatsu
- Model: PC160-7
- Location: Guangdong, China
- Features: Original air conditioning, excellent operational condition, recently serviced
| Specifications | Value |
|---|---|
| No. | 1129482 |
| Tonnage (tons) | 16 |
| Working weight (kg) | 16500 |
| Bucket capacity (m³) | 0.65 |
| Boom length (mm) | 5150 |
| Rod length (mm) | 2610 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu SAA4D102E-2 |
| Rated power (kw/rpm) | 82.4/2200 |
| Cooling mode | water-cooling |
| Displacement (L) | 3.92 |
| Working form | 4 cylinder, direct injection, turbocharged, after cooling, mechanical full speed control; Comply with 2001 EPA/EU/ Japan Level 2 emission standards. |
| Ground specific pressure (Kpa) | 46.1 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 123 |
| Rod digging force (kN) | 86.3 |
| Travel speed (km/h) | 3.4-5.5 |
| Rotary hydraulic motor type | Axial piston motor ×1(rotary holding valve) |
| Type of walking hydraulic motor | Axial piston motor ×2(with parking brake) |
| Maximum flow of main pump (l/min) | 312 |
| Traveling Hydraulic Circuit (Mpa) | 37.3 |
| Rotary Hydraulic Circuit (Mpa) | 28.4 |
| Control Hydraulic Circuit (Mpa) | 3.2 Pilot oil circuit |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 37.3 |
| Bucket cylinders - Number × diameter × stroke (mm) | 105 * 1027 * 70 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 120 * 1342 * 85 |
| Boom cylinders - Number × diameter × stroke (mm) | 110 * 1175 * 75 |
| Fuel Tank (L) | 280 |
| Hydraulic Tank (L) | 121 |
| Engine Oil changes (L) | 14 |
| Coolant (L) | 17.3 |
| Total transport length (mm) | 8565 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2990 |
| Full cab height (mm) | 2970 |
| Counterweight ground clearance (mm) | 1055 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2390 |
| Total track length (mm) | 3965 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2490 |
| Track ground length (mm) | 3170 |
| Maximum digging radius (mm) | 8960 |
| Maximum digging depth (mm) | 5960 |
| Maximum excavation height (mm) | 8980 |
| Maximum unloading height (mm) | 6370 |
| Maximum vertical digging depth (mm) | 5040 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Maximum effective digging depth (mm) | 5740 |
