Product Description
Engineered with Komatsu's renowned 6D105 six-cylinder engine delivering 78.3kW of rated power, this PC200-1 excavator represents Japanese precision manufacturing at its finest. The 6.5L displacement engine drives a sophisticated hydraulic system with a combined tank capacity of 290L, providing consistent performance across demanding earthmoving applications. Built on proven joint venture/import standards, this 20-ton class machine achieves an impressive maximum digging depth of 6,435mm and vertical reach of 9,055mm, making it ideal for deep excavation and loading operations.
Operating specifications include:
- Working weight: 18,500kg with optimized 45kPa ground pressure
- Travel speeds: 2.2/3.6 km/h for precise positioning and efficient site mobility
- Compact transport dimensions: 9,440mm length × 2,770mm width × 2,865mm height
- 610mm track plate width with 3,060mm ground contact length for superior stability
- 260L fuel capacity supporting extended operational shifts
Currently located in Dezhou, Shandong, this backhoe-configured excavator combines Komatsu's legendary durability with the technical capabilities required for medium to heavy-duty construction, mining, and
| Specifications | Value |
|---|---|
| No. | 1027726 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 18500 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu Komatsu 6D105 |
| Rated power (kw/rpm) | 78.3 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.5 |
| Ground specific pressure (Kpa) | 45 |
| Rotation speed (rpm) | 8 |
| Travel speed (km/h) | 2.2/3.6 |
| Fuel Tank (L) | 260 |
| Hydraulic Tank (L) | 290(system included) |
| Total transport length (mm) | 9440 |
| Total transport width (mm) | 2770 |
| Total transport height (mm) | 2865 |
| Full cab height (mm) | 2865 |
| Minimum ground clearance (mm) | 455 |
| Back end turning radius (mm) | 2860 |
| Track gauge (mm) | 2160 |
| Track plate width (mm) | 610 |
| Total track width (mm) | 2770 |
| Track ground length (mm) | 3060 |
| Maximum digging depth (mm) | 6435 |
| Maximum excavation height (mm) | 9055 |
| Maximum unloading height (mm) | 6365 |
| Maximum vertical digging depth (mm) | 5735 |
