Product Description
Built for high-volume earthmoving and excavation, this 2016 Komatsu PC200-6 delivers proven performance across construction, demolition, and grading operations. Operating at 20 tons with a robust 0.8m³ backhoe bucket, this machine handles foundation work, trenching, and material loading with industrial-grade reliability. The Komatsu S6D102E engine generates 99kW at 2200rpm, driving a 412 l/min hydraulic system designed for consistent digging force and cycle times.
- Maximum digging depth: 4965mm for deep utility work and basements
- Maximum digging height: 8895mm for loading trucks and material handling
- 5700mm boom and 1840mm arm configuration optimized for versatile reach
- 70% gradeability (35°) for site mobility on challenging terrain
- 2750mm tail swing radius enables operation in confined spaces
- 340L fuel tank supports extended shift operations
Currently located in Shenzhen, Guangdong, this PC200-6 is inspection-ready and available for immediate deployment. Standard transport dimensions (9510mm × 2800mm × 2985mm) facilitate logistics planning. Contact Fair Trade Machinery for detailed specifications, inspection scheduling, and worldwide shipping arrangements.
| Specifications | Value |
|---|---|
| No. | 1017470 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 19180 |
| Bucket capacity (m³) | 0.8 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 1840 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu Komatsu S6D102E |
| Rated power (kw/rpm) | 99/2200 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 5.9 |
| Ground specific pressure (Kpa) | 44.1 |
| Rotation speed (rpm) | 12.4 |
| Climbing ability (%) | 70/35 ° |
| Travel speed (km/h) | 5.5 |
| Main overflow set pressure (Mpa) | 34.818 |
| Maximum flow of main pump (l/min) | 412 |
| Fuel Tank (L) | 340 |
| Hydraulic System (L) | 166 |
| Total transport length (mm) | 9510 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 2985 |
| Full cab height (mm) | 2905 |
| Counterweight ground clearance (mm) | 440 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2750 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3270 |
| Maximum excavation height (mm) | 8895 |
| Maximum unloading height (mm) | 6065 |
| Maximum vertical digging depth (mm) | 4965 |
