Product Description
This 2020 Komatsu PC200-6 excavator with square arm configuration is available from Guangdong, China. The PC200-6 remains a proven workhorse in the 20-ton class, known for reliable performance in construction, earthmoving, and material handling applications. This unit features the standard square arm design, offering versatility for general excavation work and site preparation tasks.
Key specifications:
- Operating weight: approximately 19,900 kg
- Engine: Komatsu SAA6D102E-2
- Hydraulic system designed for productive cycle times
- Square arm configuration for standard excavation duties
- Suitable for contractors and earthwork operations
This well-maintained excavator is ready for immediate deployment. Contact us for inspection arrangements, shipping quotes, and additional documentation.
| Specifications | Value |
|---|---|
| No. | 1084677 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 19180 |
| Bucket capacity (m³) | 0.8 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 1840 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu Komatsu S6D102E |
| Rated power (kw/rpm) | 99/2200 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 5.9 |
| Ground specific pressure (Kpa) | 44.1 |
| Rotation speed (rpm) | 12.4 |
| Climbing ability (%) | 70/35 ° |
| Travel speed (km/h) | 5.5 |
| Main overflow set pressure (Mpa) | 34.818 |
| Maximum flow of main pump (l/min) | 412 |
| Fuel Tank (L) | 340 |
| Hydraulic System (L) | 166 |
| Total transport length (mm) | 9510 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 2985 |
| Full cab height (mm) | 2905 |
| Counterweight ground clearance (mm) | 440 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2750 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3270 |
| Maximum excavation height (mm) | 8895 |
| Maximum unloading height (mm) | 6065 |
| Maximum vertical digging depth (mm) | 4965 |
