Product Description
Available now from our 江苏 facility, this 2016 Komatsu PC200-7 hydraulic excavator delivers 20-ton class performance without factory lead times. Powered by a robust Komatsu SAA6D102E-2 engine producing 107 kW, this machine combines proven reliability with immediate deployment capability. Equipped with a 0.8 m³ bucket and dual rod length options (1840/2410 mm), it tackles earthmoving, foundation work, and loading operations with 149 kN bucket digging force and 145 kN rod digging force.
Key specifications include:
- Operating weight: 20,253 kg with superior stability
- Maximum digging reach: 9,380 mm for extended work zones
- Maximum digging depth: 5,380 mm for deep excavations
- Variable piston pumps: 2×214 L/min flow for responsive hydraulics
- Travel speed: 12.4 km/h for efficient site mobility
- Fuel capacity: 400 L for extended operation
Skip months of factory waiting. Fast deployment to your site from 江苏 means your project starts immediately. Ready for inspection and shipment worldwide.
| Specifications | Value |
|---|---|
| No. | 1022513 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 20253 |
| Bucket capacity (m³) | 0.8 |
| Rod length (mm) | 1840/2410 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu Komatsu SAA6D102E-2 |
| Rated power (kw/rpm) | 107 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 120 |
| Displacement (L) | 5.883 |
| Working form | 4 stroke, water cooled, direct injection |
| Bucket digging force (kN) | 149 |
| Rod digging force (kN) | 145 |
| Travel speed (km/h) | 12.4 |
| Maximum flow of main pump (l/min) | 2*214 |
| Traveling Hydraulic Circuit (Mpa) | 37.3 |
| Rotary Hydraulic Circuit (Mpa) | 28.9 |
| Control Hydraulic Circuit (Mpa) | 3.2 |
| Main pump type | Variable piston pump |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 143 |
| Engine Oil changes (L) | 24 |
| Coolant (L) | 22.4 |
| Total transport length (mm) | 9480 |
| Total transport width (mm) | 3000 |
| Total transport height (mm) | 2985 |
| Full cab height (mm) | 2095 |
| Back end turning radius (mm) | 3270 |
| Total track length (mm) | 4080 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3000 |
| Track ground length (mm) | 3270 |
| Maximum digging radius (mm) | 9380 |
| Maximum digging depth (mm) | 5380 |
| Maximum excavation height (mm) | 9800 |
| Maximum unloading height (mm) | 6890 |
| Maximum excavation radius of stop surface (mm) | 8660 |
see more
