Product Description
Engineered for precision and operator confidence, this 2013 Komatsu PC200-8N1 delivers reliable performance in demanding excavation environments. Powered by a Komatsu SAA6D107E-1-A engine producing 110 kW at 2000 rpm, this 20-ton excavator combines robust hydraulic power with refined control systems. The spacious cabin provides exceptional visibility across the 9875mm maximum digging radius, allowing operators to maintain full awareness of the work zone throughout extended shifts.
- Responsive hydraulic controls with 34.8 MPa working circuit pressure for precise bucket and arm movements
- Low ground pressure of 44.1 kPa ensures stability on varied terrain without sacrificing maneuverability
- Ergonomic operator station designed for reduced fatigue during long operational hours
- Wide 600mm track plates and 2200mm gauge deliver superior balance and traction
- Clear sightlines to attachment points enhance safety and positioning accuracy
- Proven Japanese engineering with joint venture manufacturing standards
Currently located in Guangzhou, Guangdong, this machine represents dependable mid-size excavation capability with operator-focused design elements that prioritize comfo
| Specifications | Value |
|---|---|
| No. | 1006082 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 19500 |
| Bucket capacity (m³) | 0.8 |
| Rod length (mm) | 2900 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu SAA6D107E-1-A |
| Rated power (kw/rpm) | 110/2000 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.69 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 44.1 |
| Rotation speed (rpm) | 12.4 |
| Bucket digging force (kN) | 149 |
| Rod digging force (kN) | 108 |
| Travel speed (km/h) | 5.5/4.1/3.0 |
| Rotary hydraulic motor type | Fixed displacement axial piston motor |
| Type of walking hydraulic motor | Variable axial piston motor |
| Traveling Hydraulic Circuit (Mpa) | 37.3 |
| Working Hydraulic Circuit (Mpa) | 34.8 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 135 |
| Hydraulic System (L) | 232 |
| Total transport length (mm) | 9425 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3040 |
| Minimum turning radius of front working device (mm) | 3040 |
| Back end turning radius (mm) | 2750 |
| Total track length (mm) | 4070 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Maximum digging radius (mm) | 9875 |
| Maximum digging depth (mm) | 6620 |
| Maximum excavation height (mm) | 10000 |
| Maximum unloading height (mm) | 1110 |
| Maximum excavation radius of stop surface (mm) | 9700 |
