Product Description
Powered by the proven Komatsu SA6D102 engine delivering 118 kW at 2300 rpm, this 2016 PC240-6 represents precision-engineered excavation performance. The 5.9L displacement unit drives a robust 166-liter hydraulic system designed for demanding applications, while the 24-ton operating weight provides exceptional stability across diverse terrain conditions.
Engineering excellence defines this model series through measurable capabilities:
- Maximum digging depth of 5,880 mm with 9,090 mm reach at ground level
- Versatile bucket configurations: 1.1 m³ standard, 0.49 m³ precision, or 1.3 m³ high-capacity
- 9,070 mm maximum excavation height for elevated loading operations
- 2,860 mm rear swing radius enables confined-space maneuverability
- 310-liter fuel capacity supports extended operational cycles
Currently located in Kunming, Yunnan, this joint-venture manufactured excavator combines Komatsu's renowned durability with practical transport dimensions (9,735 × 2,980 × 3,005 mm). The 600 mm track plates and 50.3 kPa ground pressure deliver reliable traction without excessive surface disruption, making this machine suitable for infrastructure, mining, and general construction p
| Specifications | Value |
|---|---|
| No. | 1031082 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 23500 |
| Bucket capacity (m³) | 1.1/0.49/1.3 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu Komatsu SA6D102 |
| Rated power (kw/rpm) | 118/2300 |
| Displacement (L) | 5.9 |
| Ground specific pressure (Kpa) | 50.3 |
| Travel speed (km/h) | 5.5 |
| Fuel Tank (L) | 310 |
| Hydraulic System (L) | 166 |
| Total transport length (mm) | 9735 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3005 |
| Full cab height (mm) | 2905 |
| Counterweight ground clearance (mm) | 1070 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2860 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3445 |
| Maximum digging depth (mm) | 5880 |
| Maximum excavation height (mm) | 9070 |
| Maximum unloading height (mm) | 6120 |
| Maximum vertical digging depth (mm) | 4800 |
| Maximum excavation radius of stop surface (mm) | 9090 |
