Product Description
Built for serious excavation work, this 2019 Komatsu PC240-6 delivers proven 24-ton performance at a fraction of new equipment cost. Powered by the reliable Komatsu SA6D102 engine producing 118 kW at 2,300 RPM with a 5.9L displacement, this machine handles demanding dig cycles without compromise. Currently located in Zhejiang, China, it is available for global export with straightforward logistics.
Investing in a quality used PC240-6 means acquiring a joint-venture/import-grade machine with verified specs — not a gamble. With a maximum digging depth of 5,880 mm, a 9,070 mm excavation height, and a 1.1 m³ backhoe bucket, productivity on commercial and civil projects remains fully intact.
- Working Weight: 23,500 kg | Ground Pressure: 50.3 kPa
- Rated Power: 118 kW / 2,300 RPM | Engine: SA6D102 (5.9L)
- Bucket Capacity: 1.1 / 0.49 / 1.3 m³ (backhoe configuration)
- Max Digging Depth: 5,880 mm | Max Excavation Radius: 9,090 mm
- Fuel Tank: 310 L | Hydraulic System: 166 L
- Track Plate Width: 600 mm | Travel Speed: 5.5 km/h
- Transport Dimensions: 9,735 mm (L) × 2,980 mm (W) × 3,005 mm (H)
Strong residual value, lower acquisition cost, and fully operational specs make this PC240-6 a straightforward business decision for contractors who need reliable output without new-machine pricing.
| Specifications | Value |
|---|---|
| No. | 1090284 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 23500 |
| Bucket capacity (m³) | 1.1/0.49/1.3 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu Komatsu SA6D102 |
| Rated power (kw/rpm) | 118/2300 |
| Displacement (L) | 5.9 |
| Ground specific pressure (Kpa) | 50.3 |
| Travel speed (km/h) | 5.5 |
| Fuel Tank (L) | 310 |
| Hydraulic System (L) | 166 |
| Total transport length (mm) | 9735 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3005 |
| Full cab height (mm) | 2905 |
| Counterweight ground clearance (mm) | 1070 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2860 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3445 |
| Maximum digging depth (mm) | 5880 |
| Maximum excavation height (mm) | 9070 |
| Maximum unloading height (mm) | 6120 |
| Maximum vertical digging depth (mm) | 4800 |
| Maximum excavation radius of stop surface (mm) | 9090 |
