2020 Komatsu PC240-6

Built for serious excavation work, this 2020 Komatsu PC240-6 arrives from Zhejiang, China, ready to move to your next job site without delay. Powered by the Komatsu SA6D102 engine producing 118 kW at 2,300 rpm with a 5.9L displacement, it delivers consistent, reliable performance across demanding digging, grading, and demolition applications.

At 23,500 kg working weight with a 1.1 m³ backhoe bucket, this 24-ton machine handles heavy material cycles efficiently. A maximum digging depth of 5,880 mm and excavation radius of 9,090 mm give operators the reach needed for deep trenching and wide-area site clearing. Maximum unloading height of 6,120 mm keeps truck-loading operations productive.

• Engine: Komatsu SA6D102 — 118 kW / 2,300 rpm, 5.9L displacement
• Bucket capacity: 1.1 m³ (standard) / 0.49 m³ / 1.3 m³
• Max digging depth: 5,880 mm | Max excavation radius: 9,090 mm
• Max unloading height: 6,120 mm | Max excavation height: 9,070 mm
• Working weight: 23,500 kg | Ground pressure: 50.3 kPa
• Fuel tank: 310 L | Hydraulic system: 166 L
• Track plate width: 600 mm | Travel speed: 5.5 km/h
• Transport dimensions: 9,735 mm (L) × 2,980 mm (W) × 3,005 mm (H)

With a 310-liter fuel tank and 166-liter hydraulic system, this PC240-6 is sized for long shifts with minimal downtime. Located in Zhejiang, China — available for prompt inspection and export.
