Product Description
Engineered with Komatsu's proven SAA6D114E turbocharged engine, this PC360-7 delivers 180 kW of reliable power at 1900 rpm through an 8.27L water-cooled, 6-cylinder direct injection system. Hydraulic performance stands at the core of its capability, featuring a 535 L/min maximum main pump flow and precision axial plunger motors that drive both rotation and travel functions. Operating at 37.3 MPa traveling pressure and 27.9 MPa rotary pressure, the hydraulic circuit provides exceptional digging force—227 kN bucket force and 171 kN arm force—enabling efficient material handling across demanding applications.
Built on a 33,000 kg working platform with 67.7 kPa ground pressure distribution, this 36-ton excavator combines reach and stability. Key performance specifications include:
- Maximum digging reach: 11,100 mm with 7,380 mm depth capability
- 6,470 mm boom and 3,185 mm arm configuration with 1.6 m³ bucket capacity
- 9.5 rpm rotation speed with 3,450 mm rear turning radius
- Variable travel speeds: 3.2/4.5/5.5 km/h for operational flexibility
- 70% (35°) gradeability for challenging terrain navigation
Currently located in Shenzhen, Guangdong, this joint-venture manufactu
| Specifications | Value |
|---|---|
| No. | 1019604 |
| Tonnage (tons) | 36 |
| Working weight (kg) | 33000 |
| Bucket capacity (m³) | 1.6 |
| Boom length (mm) | 6470 |
| Rod length (mm) | 3185 |
| Country of origin | Jining, Shandong Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu SAA6D114E |
| Rated power (kw/rpm) | 180/1900 |
| Cooling mode | water-cooling |
| Displacement (L) | 8.27 |
| Working form | 6-cylinder, water-cooled, direct injection, turbocharged, mechanical full speed regulation; Cylinder diameter × stroke :114mm×135mm |
| Ground specific pressure (Kpa) | 67.7 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 227 |
| Rod digging force (kN) | 171 |
| Travel speed (km/h) | 3.2/4.5/5.5 |
| Rotary hydraulic motor type | Axial plunger type ×1 |
| Type of walking hydraulic motor | Axial plunger type x 2 |
| Maximum flow of main pump (l/min) | 535L/min |
| Traveling Hydraulic Circuit (Mpa) | 37.3 |
| Rotary Hydraulic Circuit (Mpa) | 27.9 |
| Control Hydraulic Circuit (Mpa) | 3.2 |
| Hydraulic crushing pipeline is standard | no |
| Bucket cylinders - Number × diameter × stroke (mm) | 150 * 1285 * 110 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 160 * 1825 * 110 |
| Boom cylinders - Number × diameter × stroke (mm) | 140 * 1480 * 100 |
| Fuel Tank (L) | 605 |
| Hydraulic Tank (L) | 188 |
| Engine Oil changes (L) | 35 |
| Coolant (L) | 32 |
| Total transport length (mm) | 11140 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3280 |
| Full cab height (mm) | 3130 |
| Counterweight ground clearance (mm) | 1185 |
| Minimum ground clearance (mm) | 500 |
| Back end turning radius (mm) | 3450 |
| Total track length (mm) | 4625 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 3700 |
| Maximum digging radius (mm) | 11100 |
| Maximum digging depth (mm) | 7380 |
| Maximum excavation height (mm) | 10210 |
| Maximum unloading height (mm) | 7110 |
| Maximum vertical digging depth (mm) | 6480 |
| Bulldozer lift or depth (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 10920 |
| Maximum effective digging depth (mm) | 7180 |
