Product Description
Built for demanding excavation work, this 2014 Komatsu PC360-7 delivers 36 tons of proven performance across construction, demolition, and grading operations. Powered by a Komatsu SAA6D114E engine producing 180 kW at 1900 rpm, this machine combines hydraulic efficiency with exceptional digging force—227 kN bucket force and 171 kN arm force tackle compacted soil, rock breaking, and heavy material handling with confidence.
Equipped with a 1.6 m³ backhoe bucket, 6470 mm boom, and 3185 mm arm, the PC360-7 reaches 11.1 meters horizontally and digs 7.38 meters deep. Maximum flow of 535 L/min from the main pump ensures responsive cycle times, while the water-cooled 8.27L turbocharged engine provides reliable power in extended shifts. Travel speeds up to 5.5 km/h optimize site mobility.
- Working weight: 33,000 kg for stable operation on varied terrain
- Maximum digging height: 10,210 mm for truck loading efficiency
- 70% gradeability (35°) handles steep slopes confidently
- 605L fuel capacity reduces refueling downtime
- Currently located in Jiangxi, ready for immediate deployment
Site-ready condition. Contact Fair Trade Machinery for inspection details and shipping arrangement
| Specifications | Value |
|---|---|
| No. | 1051097 |
| Tonnage (tons) | 36 |
| Working weight (kg) | 33000 |
| Bucket capacity (m³) | 1.6 |
| Boom length (mm) | 6470 |
| Rod length (mm) | 3185 |
| Country of origin | Jining, Shandong Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu SAA6D114E |
| Rated power (kw/rpm) | 180/1900 |
| Cooling mode | water-cooling |
| Displacement (L) | 8.27 |
| Working form | 6-cylinder, water-cooled, direct injection, turbocharged, mechanical full speed regulation; Cylinder diameter × stroke :114mm×135mm |
| Ground specific pressure (Kpa) | 67.7 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 227 |
| Rod digging force (kN) | 171 |
| Travel speed (km/h) | 3.2/4.5/5.5 |
| Rotary hydraulic motor type | Axial plunger type ×1 |
| Type of walking hydraulic motor | Axial plunger type x 2 |
| Maximum flow of main pump (l/min) | 535L/min |
| Traveling Hydraulic Circuit (Mpa) | 37.3 |
| Rotary Hydraulic Circuit (Mpa) | 27.9 |
| Control Hydraulic Circuit (Mpa) | 3.2 |
| Hydraulic crushing pipeline is standard | no |
| Bucket cylinders - Number × diameter × stroke (mm) | 150 * 1285 * 110 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 160 * 1825 * 110 |
| Boom cylinders - Number × diameter × stroke (mm) | 140 * 1480 * 100 |
| Fuel Tank (L) | 605 |
| Hydraulic Tank (L) | 188 |
| Engine Oil changes (L) | 35 |
| Coolant (L) | 32 |
| Total transport length (mm) | 11140 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3280 |
| Full cab height (mm) | 3130 |
| Counterweight ground clearance (mm) | 1185 |
| Minimum ground clearance (mm) | 500 |
| Back end turning radius (mm) | 3450 |
| Total track length (mm) | 4625 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 3700 |
| Maximum digging radius (mm) | 11100 |
| Maximum digging depth (mm) | 7380 |
| Maximum excavation height (mm) | 10210 |
| Maximum unloading height (mm) | 7110 |
| Maximum vertical digging depth (mm) | 6480 |
| Bulldozer lift or depth (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 10920 |
| Maximum effective digging depth (mm) | 7180 |
