Product Description
Built for serious earthmoving, the 2020 Komatsu PC450-7 delivers 45-ton class performance at a fraction of new equipment cost. Powered by the Komatsu SAA6D125E-3 six-cylinder turbocharged engine producing 259 kW, this machine combines proven reliability with the kind of digging force — 278 kN bucket, 233 kN arm — that handles demanding cut-and-fill, quarry, and mass excavation work without breaking stride.
Sourced directly from Guangdong, China, this unit represents a smart capital allocation for contractors who need heavy iron without heavy depreciation on a brand-new machine.
- Working weight: 43,000–43,420 kg | Bucket capacity: 2.1 m³
- Engine: Komatsu SAA6D125E-3 | Rated power: 259 kW / 1,850 rpm | Displacement: 11.04 L
- Max digging depth: 7,790 mm | Max digging radius: 12,005 mm
- Max excavation height: 10,925 mm | Max unloading height: 7,625 mm
- Travel speed: 3.0 / 4.4 / 5.5 km/h | Climbing ability: 70% / 35°
- Main pump max flow: 690 L/min | Fuel tank: 650 L | Hydraulic tank: 248 L
- Track plate width: 600/700 mm | Ground pressure: 84.1 kPa
- Transport dimensions: 12,040 mm (L) × 3,340 mm (W) × 3,660 mm (H)
For operations prioritizing uptime, output, and return on investment, this PC450-7 checks every box — proven engineering, full-size productivity, and immediate availability from stock.
| Specifications | Value |
|---|---|
| No. | 1086361 |
| Tonnage (tons) | 45 |
| Working weight (kg) | 43000-43420 |
| Bucket capacity (m³) | 2.1 |
| Boom length (mm) | 7060 |
| Rod length (mm) | 3380 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu SAA6D125E-3 |
| Rated power (kw/rpm) | 259/1850 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 125 x 150 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 11.04 |
| Working form | 6-cylinder, water-cooled, direct injection, turbocharged, electronic speed regulation; Cylinder diameter × stroke: |
| Ground specific pressure (Kpa) | 84.1 |
| Rotation speed (rpm) | 9 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 278 |
| Rod digging force (kN) | 233 |
| Travel speed (km/h) | 3.0/4.4/5.5 |
| Rotary hydraulic motor type | Axial plunger type ×1 |
| Type of walking hydraulic motor | Axial plunger type x 2 |
| Maximum flow of main pump (l/min) | 690 |
| Traveling Hydraulic Circuit (Mpa) | 37.3 |
| Rotary Hydraulic Circuit (Mpa) | 27.9 |
| Control Hydraulic Circuit (Mpa) | 3.2 Pilot oil circuit |
| Hydraulic crushing pipeline is standard | no |
| Bucket cylinders - Number × diameter × stroke (mm) | 160 * 1270 * 110 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 185 * 1985 * 130 |
| Boom cylinders - Number × diameter × stroke (mm) | 160 * 1570 * 110 |
| Fuel Tank (L) | 650 |
| Hydraulic Tank (L) | 248 |
| Engine Oil changes (L) | 37 |
| Coolant (L) | 36 |
| Total transport length (mm) | 12040 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 3660 |
| Full cab height (mm) | 3265 |
| Counterweight ground clearance (mm) | 1320 |
| Minimum ground clearance (mm) | 555 |
| Back end turning radius (mm) | 3605 |
| Total track length (mm) | 5055 |
| Track gauge (mm) | 2890(2392 when contracted) |
| Track plate width (mm) | 600/700 |
| Total track width (mm) | 3490(2992 when contracted) |
| Track ground length (mm) | 4020 |
| Maximum digging radius (mm) | 12005 |
| Maximum digging depth (mm) | 7790 |
| Maximum excavation height (mm) | 10925 |
| Maximum unloading height (mm) | 7625 |
| Maximum vertical digging depth (mm) | 6600 |
| Bulldozer lift or depth (mm) | No dodging plate |
| Maximum excavation radius of stop surface (mm) | 11800 |
