Product Description
Engineered with Komatsu's proven SAA6D125E-5 powerplant, this 2016 PC460LC-8 delivers 257 kW at 1900 rpm through an 11.04L water-cooled six-cylinder configuration. Hydraulic performance centers on a variable piston pump system supplying 690 l/min flow capacity, with working circuit pressure rated at 37.8 MPa for consistent breakout force across demanding applications. Bucket digging force reaches 278 kN, while stick digging force measures 233 kN—specifications that translate directly to productivity in high-density material.
- Operating Weight: 46,000 kg with 2.1 m³ bucket capacity
- Reach Envelope: 12,005 mm maximum digging radius, 7,790 mm maximum depth
- Boom/Arm Configuration: 7,060 mm boom, 3,380 mm stick length
- Undercarriage: 600 mm triple-grouser shoes, 79.3 kPa ground pressure
- Travel Performance: 5.5 km/h high-speed mode, 70% gradeability
- Location: Zhejiang Province, China
Dual boom cylinders (160 mm diameter) and reinforced stick cylinder design (185 mm bore) provide structural durability for extended service intervals. Factory joint-venture manufacturing s
| Specifications | Value |
|---|---|
| No. | 1031429 |
| Tonnage (tons) | 46 |
| Working weight (kg) | 46000 |
| Bucket capacity (m³) | 2.1 |
| Boom length (mm) | 7060 |
| Rod length (mm) | 3380 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | SAA6D125E-5 |
| Rated power (kw/rpm) | 257/1900 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 125*150 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 11.04 |
| Ground specific pressure (Kpa) | 79.3 |
| Rotation speed (rpm) | 9.1 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 278 |
| Rod digging force (kN) | 233 |
| Maximum tractive force (kN) | 330 |
| Travel speed (km/h) | 5.5/4.2/3.0 |
| Maximum flow of main pump (l/min) | 690 |
| Traveling Hydraulic Circuit (Mpa) | 37.8 |
| Rotary Hydraulic Circuit (Mpa) | 27.9 |
| Main pump type | Variable piston pump |
| Working Hydraulic Circuit (Mpa) | 37.8 |
| Pilot Oil Circuit (MPa) | 3.3 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-160*1270 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-185*1985 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-160*1570 |
| Fuel Tank (L) | 650 |
| Hydraulic Tank (L) | 248 |
| Engine Oil changes (L) | 37 |
| Total transport length (mm) | 12040 |
| Total transport width (mm) | 3570 |
| Total transport height (mm) | 3660 |
| Counterweight ground clearance (mm) | 1320 |
| Minimum ground clearance (mm) | 567 |
| Minimum turning radius of front working device (mm) | 4805 |
| Back end turning radius (mm) | 3645 |
| Total track length (mm) | 5385 |
| Track gauge (mm) | 2740 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3340 |
| Track ground length (mm) | 4350 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 12005 |
| Maximum digging depth (mm) | 7790 |
| Maximum excavation height (mm) | 10925 |
| Maximum unloading height (mm) | 7625 |
| Maximum vertical digging depth (mm) | 6600 |
| Maximum excavation radius of stop surface (mm) | 11800 |
