Product Description
Built in Japan and engineered for decades of reliable service, this 2020 Komatsu PC60-7 delivers serious excavation capability at a fraction of new equipment costs. Powered by the proven Komatsu 4D95LE engine producing 40 kW at 2,100 RPM, this 6-tonne machine punches well above its weight class — making it a smart acquisition for contractors who demand performance without the premium price tag.
Currently located in Sichuan, China, and ready for export, this compact excavator offers a maximum digging depth of 4,100 mm, a digging radius of 6,360 mm, and a bucket digging force of 54.8 kN — specs that rival newer models at a significantly lower capital outlay.
- Engine: Komatsu 4D95LE | 40 kW / 2,100 RPM | 3.26L Displacement
- Operating Weight: 6,300 kg | Ground Pressure: 28.4 kPa
- Bucket Capacity: 0.28–0.37 m³ | Digging Force: 54.8 kN
- Max Digging Depth: 4,100 mm | Max Digging Radius: 6,360 mm
- Travel Speed: 2.8–4.5 km/h | Max Tractive Force: 56.37 kN
- Hydraulic Main Pump Flow: 155 L/min | Working Circuit: 24.5 MPa
- Fuel Tank: 130 L | Hydraulic Tank: 90 L
- Transport Dimensions: 6,080 × 2,225 × 2,590 mm
For operations prioritizing cost efficiency, the PC60-7 represents a proven, low-risk investment — backed by Komatsu's global parts network and a track record of durability across demanding job sites worldwide.
| Specifications | Value |
|---|---|
| No. | 1093126 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 6300 |
| Bucket capacity (m³) | 0.28-0.37 |
| Boom length (mm) | 3710 |
| Rod length (mm) | 1650 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu 4D95LE |
| Rated power (kw/rpm) | 40/2100 |
| Displacement (L) | 3.26 |
| Working form | 4-stroke, water-cooled, direct injection engine; Cylinder diameter :95mm; Travel :115mm; Mechanical full speed regulation. |
| Ground specific pressure (Kpa) | 28.4 |
| Rotation speed (rpm) | 12 |
| Bucket digging force (kN) | 54.8kN |
| Rod digging force (kN) | 37.3kN |
| Maximum tractive force (kN) | 56.37KN |
| Travel speed (km/h) | 2.8-4.5 |
| Rotary hydraulic motor type | Axial plunger type ×1 |
| Type of walking hydraulic motor | Axial plunger type x 2 |
| Maximum flow of main pump (l/min) | 155L/min |
| Traveling Hydraulic Circuit (Mpa) | 24.5 |
| Rotary Hydraulic Circuit (Mpa) | 19.1 |
| Control Hydraulic Circuit (Mpa) | 2.9 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 24.5 |
| Bucket cylinders - Number × diameter × stroke (mm) | 90 x 710 x 60 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 100 x 865 x 60 |
| Boom cylinders - Number × diameter × stroke (mm) | 115 * 840 * 65 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 90 |
| Engine Oil changes (L) | 11 |
| Coolant (L) | 10.3 |
| Total transport length (mm) | 6080 |
| Total transport width (mm) | 2225 |
| Total transport height (mm) | 2590 |
| Full cab height (mm) | 2590 |
| Counterweight ground clearance (mm) | 750 |
| Minimum ground clearance (mm) | 350 |
| Back end turning radius (mm) | 1750 |
| Total track length (mm) | 2765 |
| Track gauge (mm) | 1700 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2150 |
| Track ground length (mm) | 2130 |
| Maximum digging radius (mm) | 6360 |
| Maximum digging depth (mm) | 4100 |
| Maximum excavation height (mm) | 7150 |
| Maximum unloading height (mm) | 5015 |
| Maximum vertical digging depth (mm) | 3505 |
| Bulldozer lift or depth (mm) | 270/410 |
| Maximum excavation radius of stop surface (mm) | 6220 |
| Maximum effective digging depth (mm) | 3755 |
