Product Description
Available now in Jiangxi, this 2018 Komatsu PC60-8 mini excavator eliminates factory wait times and delivers immediate productivity to your jobsite. Powered by a reliable Komatsu SAA4D95LE-5 turbocharged engine producing 40.7kW, this 6-ton workhorse combines proven Japanese engineering with rapid deployment capability. Skip the lengthy procurement process—this machine is ready for fast transport directly to your operation.
Engineered for versatile performance, the PC60-8 features impressive digging specifications: 6,190mm maximum reach, 3,900mm digging depth, and 54.8kN bucket digging force. The variable piston pump delivers 172 l/min flow through a water-cooled hydraulic system, ensuring consistent operation across demanding applications. Compact dimensions (6,035mm length, 2,225mm width) enable maneuverability in confined spaces while maintaining stability with 28.4kPa ground pressure.
- Working weight: 6,180kg with 0.25-0.37m³ bucket capacity
- Travel speed: 2.8-4.5 km/h for efficient site mobility
- Fuel capacity: 130L for extended operation
- Located in Jiangxi—immediate availability for rapid deployment
Secure this proven excavator today and accelerate your project timeli
| Specifications | Value |
|---|---|
| No. | 997197 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 6180 |
| Bucket capacity (m³) | 0.25~0.37 |
| Country of origin | Jining, Shandong Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu SAA4D95LE-5 |
| Rated power (kw/rpm) | 40.7/1950 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 95*115 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.26 |
| Working form | turbocharging |
| Ground specific pressure (Kpa) | 28.4 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 54.8 |
| Rod digging force (kN) | 39.8 |
| Maximum tractive force (kN) | 56.6 |
| Travel speed (km/h) | 2.8-4.5 |
| Maximum flow of main pump (l/min) | 172 |
| Traveling Hydraulic Circuit (Mpa) | 24.5 |
| Rotary Hydraulic Circuit (Mpa) | 21.1 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Variable piston pump |
| Working Hydraulic Circuit (Mpa) | 24.5 |
| Pilot Oil Circuit (MPa) | 2.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-90*710 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-100*865 |
| Boom cylinders - Number × diameter × stroke (mm) | 1-115*840 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 95 |
| Engine Oil changes (L) | 12.5 |
| Coolant (L) | 10 |
| Total transport length (mm) | 6035 |
| Total transport width (mm) | 2225 |
| Total transport height (mm) | 2620 |
| Counterweight ground clearance (mm) | 750 |
| Minimum ground clearance (mm) | 350 |
| Minimum turning radius of front working device (mm) | 1700 |
| Back end turning radius (mm) | 1750 |
| Total track length (mm) | 2765 |
| Track gauge (mm) | 1700 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2150 |
| Track ground length (mm) | 2130 |
| Number of sprockets (single side) (each) | 1 |
| Number of wheels (single side) (each) | 5 |
| Number of track plates (single side) (PCS) | 38 |
| Maximum digging radius (mm) | 6190 |
| Maximum digging depth (mm) | 3900 |
| Maximum excavation height (mm) | 7030 |
| Maximum unloading height (mm) | 4925 |
| Maximum vertical digging depth (mm) | 3350 |
| Maximum excavation radius of stop surface (mm) | 6045 |
