Product Description
Discover the reliability and durability of this 2020 Liebherr 920, available in Hunan, China. This used heavy machine has accumulated over 15,000 operational hours, demonstrating its robustness and efficiency in demanding environments. Ideal for a variety of industrial applications, the Liebherr 920 is known for its high performance, ease of maintenance, and fuel efficiency. It's an excellent choice for businesses looking to enhance their fleet with a proven workhorse that can handle tough tasks with precision and power.
- Year: 2020
- Brand: Liebherr
- Model: 920
- Location: Hunan, China
- Operational Hours: Over 15,000
| Specifications | Value |
|---|---|
| No. | 1121917 |
| Tonnage (tons) | 9 |
| Working weight (kg) | 11300 |
| Bucket capacity (m³) | 0.15-0.44 |
| Boom length (mm) | 2100 |
| Rod length (mm) | 1850 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Deutz TCD2012 L04 |
| Rated power (kw/rpm) | 65/1800 |
| Total displacement (L) | 4 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 101 x 126 |
| Forward speed (Km/h) | 0-20.0 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 76.3 |
| Rod digging force (kN) | 44.8 |
| Minimum turning radius (m) | 6.26 (front wheel Drive) /4.57 (four wheel drive) |
| Rotary hydraulic motor type | Liebherr swashplate variable variable hydraulic motor |
| Type of walking hydraulic motor | Liebherr swash plate hydraulic motor |
| Maximum flow of main pump (l/min) | 194 |
| Main pump type | Liebherr swashplate variable pump |
| Fuel Tank (L) | 210 |
| Hydraulic Tank (L) | 100 |
| Hydraulic System (L) | 210 |
| Total transport length (mm) | 8300 |
| Total transport width (mm) | 2550 |
| Total transport height (mm) | 3110 |
| Full cab height (mm) | 3110 |
| Counterweight ground clearance (mm) | 1170 |
| Wheelbase (mm) | 2400 |
| Total tire outside width (mm) | 2525 |
| Minimum ground clearance (mm) | 320 |
| Back end turning radius (mm) | 1600 |
| Maximum excavation radius (mm) | 8150 |
| Maximum digging depth (mm) | 3900 |
| Maximum excavation height (mm) | 8600 |
| Maximum unloading height (mm) | 6150 |
| Dodging plate width × height (mm) | 2550 x 620 |
