Product Description
Discover the 2020 Liebherr R924 Excavator, available in Fujian, China. This machine is in excellent condition, rated at 9 out of 10, and has only 360 operating hours, making it a prime choice for your heavy machinery needs. The R924 is known for its robust design and high performance, ideal for various construction and excavation projects.
- Year: 2020
- Brand: Liebherr
- Model: R924
- Location: Fujian, China
- Condition: 9 out of 10
- Operating Hours: 360
| Specifications | Value |
|---|---|
| No. | 1086389 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 23,900-24,850 |
| Bucket capacity (m³) | 1.45 |
| Boom length (mm) | 5900 |
| Rod length (mm) | 2000/2500/3000 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Cummins QSB 6.7 |
| Rated power (kw/rpm) | 125/1800 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 107 * 124 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | 4-stroke diesel engine common rail, turbocharged |
| Rotation speed (rpm) | 0-11.3 |
| Bucket digging force (kN) | 157 |
| Maximum tractive force (kN) | 228 |
| Travel speed (km/h) | 3.0/5.0 |
| Turning torque (Nm) | 73.3 |
| Maximum flow of main pump (l/min) | 2 x 216 |
| Main pump type | In-line double swash plate variable pump |
| Fuel Tank (L) | 580 |
| Hydraulic Tank (L) | 100 |
| Hydraulic System (L) | 300 |
| Maximum digging depth (mm) | 6950 |
| Maximum excavation height (mm) | 9850 |
| Maximum unloading height (mm) | 6950 |
| Maximum excavation radius of stop surface (mm) | 10100 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8/9 |
