Product Description
Engineered with robust hydraulic architecture, this 2019 CLG860H wheel loader delivers 195 kN of digging force powered by a 180 kW engine, making it a formidable choice for demanding earthmoving operations. LiuGong's H-series design emphasizes mechanical reliability through a reinforced drivetrain and optimized power distribution across its 19,500 kg operating weight. With a 6,000 kg rated load capacity and 3,100 mm maximum unloading height, this model handles material transfer with industrial-grade efficiency.
Performance specifications include:
- Dual-speed transmission: 11.5/15.5 km/h (1st gear), 37 km/h (2nd gear)
- Compact maneuverability: 3,450 mm wheelbase, 2,280 mm wheel base
- Overall dimensions: 8,628 mm × 3,046 mm × 3,467 mm
- 10-second ternary cycle time for rapid load-dump-return operations
- Located in Baoding, Hebei Province
Built on LiuGong's proven CLG860 platform, this 2019 unit combines hydraulic precision with structural durability for continuous-duty applications in construction, mining, and material handling environments.
| Specifications | Value |
|---|---|
| No. | 1013476 |
| Rated power (kw/rpm) | 180 |
| Bucket capacity (m³) | |
| Rated load (tons) | |
| Rated load (kg) | 6000 |
| Digging force (lifting force) (kN) | 195 |
| Machine operating weight (kg) | 19500 |
| Max - Unloading height (mm) | 3100 |
| Wheelbase (mm) | 3450 |
| Wheel base (mm) | 2280 |
| Machine length (mm) | 8628 |
| Machine width (mm) | 3046 |
| Machine height (mm) | 3467 |
| Ternary sum (s) | 10 |
| Speed 1 gear (km/h) | 11.5/15.5 |
| Speed 2 (km/h) | 37 |
