Product Description
Featuring a robust 6.234L engine with a rated power of 92 kW at 2200 rpm, the 2012 Lonking LG833 delivers exceptional performance and reliability. With a rated working pressure of 15.7 bars, this loader is equipped to handle demanding tasks efficiently. The machine's 1.7 m³ bucket capacity and 3000 kg rated load, combined with a digging force of 101 kN, ensure high productivity in various applications. Its compact design, with a machine length of 6950 mm and width of 2500 mm, allows for maneuverability in tight spaces. The LG833 also boasts a maximum unloading height of 2900 mm and an unloading distance of 1069 mm, making it versatile for different job sites. Engineered for durability and efficiency, this model is a reliable choice for your heavy machinery needs.
- Engine Type: 6.234L, 92 kW/2200 rpm
- Bucket Capacity: 1.7 m³
- Rated Load: 3000 kg
- Digging Force: 101 kN
- Max Unloading Height: 2900 mm
- Machine Operating Weight: 10300 kg
- Speeds: 6.5/6.8 km/h (1st gear), 12/12.5 km/h (2nd gear), 32/33.5 km/h (3rd gear)
| Specifications | Value |
|---|---|
| No. | 1020940 |
| Engine type | |
| Rated power (kw/rpm) | 92/2200 |
| Working form | |
| Exhaust volume (L) | 6.234 |
| Bucket capacity (m³) | 1.7 |
| Rated load (tons) | |
| Rated load (kg) | 3000 |
| Digging force (lifting force) (kN) | 101 |
| Machine operating weight (kg) | 10300 |
| Max - Unloading height (mm) | 2900 |
| Unloading distance (mm) | 1069 |
| Minimum turning radius of outer wheel center line | 4865 |
| Turning radius - Outside of bucket (mm) | 5600 |
| Rated working pressure (bars) | 15.7 |
| Lift (s) | 6 |
| Ternary sum (s) | 10.5 |
| Speed 1 gear (km/h) | 6.5/6.8 |
| Speed 2 (km/h) | 12/12.5 |
| Speed 3 (km/h) | 32/33.5 |
| Machine length (mm) | 6950 |
| Machine width (mm) | 2500 |
| Machine height (mm) | 3120 |
