Product Description
Expand your fleet capacity with this 2016 Lonking LG855H wheel loader, a proven workhorse engineered for high-volume material handling in Baoding, Hebei. Built around a robust 5,000 kg rated load and 2.8 m³ bucket capacity, this machine delivers consistent performance across aggregate yards, construction sites, and logistics terminals. Its 3,080 mm max unloading height and 1,270 mm reach enable efficient truck loading cycles, while the 28° climbing ability ensures productivity on challenging terrain.
- Operational Efficiency: 4.8-second lift cycle and 9.3-second total cycle time maximize throughput
- Fleet Compatibility: Compact 8,080 mm length and 6,240 mm turning radius suit confined job sites
- Dual-Speed Versatility: 13 km/h (1st gear) for precision loading; 39 km/h (2nd gear) for rapid repositioning
- Reliability: 3,230 mm wheelbase and 408 mm ground clearance provide stability across uneven surfaces
Ideal as a backup unit during peak demand or as a dedicated loader for secondary operations, this LG855H integrates seamlessly into existing fleets requiring dependable mid-capacity lifting equipment.
| Specifications | Value |
|---|---|
| No. | 1021710 |
| Bucket capacity (m³) | 2.8 |
| Rated load (tons) | |
| Rated load (kg) | 5000 |
| Digging force (lifting force) (kN) | |
| Machine operating weight (kg) | |
| Max - Unloading height (mm) | 3080 |
| Unloading distance (mm) | 1270 |
| Maximum tractive force (kN) | |
| Maximum climbing ability (°) | 28 |
| Wheelbase (mm) | 3230 |
| Wheel base (mm) | 2240 |
| Minimum ground clearance (mm) | 408 |
| Machine length (mm) | 8080 |
| Machine width (mm) | 2835 |
| Machine height (mm) | 3400 |
| Minimum turning radius of outer wheel center line | 6240 |
| Turning radius - Outside of bucket (mm) | 7229 |
| Lift (s) | 4.8 |
| Ternary sum (s) | 9.3 |
| Speed 1 gear (km/h) | 13 |
| Speed 2 (km/h) | 39 |
