Product Description
Discover the reliability and performance of the 2020 Sany 305C-9, a classic model renowned for its robust construction and efficient earthmoving capabilities. Located in Hebei, China, this used excavator is well-maintained with a fully operational hydraulic and electrical system, ensuring consistent and dependable performance. Equipped with a standard earthmoving bucket, it is ideal for various construction and excavation projects. This machine offers a cost-effective solution without compromising on quality or functionality, making it a smart choice for any industrial fleet.
- Year: 2020
- Brand: Sany
- Model: 305C-9
- Location: Hebei, China
- Features: Reliable hydraulic and electrical systems, standard earthmoving bucket
| Specifications | Value |
|---|---|
| No. | 1112404 |
| Tonnage (tons) | 30 |
| Working weight (kg) | 30600 |
| Bucket capacity (m³) | 1.45 |
| Country of origin | Kunshan in Jiangsu Province |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 190.5/2000 |
| Ground specific pressure (Kpa) | 62 |
| Rotation speed (rpm) | 10.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 193 |
| Rod digging force (kN) | 165 |
| Travel speed (km/h) | 5.1/3.2 |
| Total transport length (mm) | 10560 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3430 |
| Full cab height (mm) | 3095 |
| Minimum ground clearance (mm) | 500 |
| Minimum turning radius of front working device (mm) | 4350 |
| Back end turning radius (mm) | 3250 |
| Total track length (mm) | 4625 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 3700 |
| Maximum digging radius (mm) | 10620 |
| Maximum digging depth (mm) | 7100 |
| Maximum excavation height (mm) | 9950 |
| Maximum unloading height (mm) | 6850 |
| Maximum vertical digging depth (mm) | 5680 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
| Maximum effective digging depth (mm) | 7100 |
