Product Description
Discover the reliability and efficiency of the 2020 Sany 55C-9, available for immediate acquisition from Gansu, China. This robust excavator has logged over 4,000 genuine operating hours, showcasing its durability and performance in various construction environments. Built to meet the demanding standards of heavy-duty applications, the Sany 55C-9 is a trusted choice for contractors and industrial operators seeking a blend of power, precision, and endurance.
- Year: 2020
- Brand: Sany
- Model: 55C-9
- Location: Gansu, China
- Operating Hours: Over 4,000
| Specifications | Value |
|---|---|
| No. | 1115643 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 14100 |
| Bucket capacity (m³) | 0.50~0.65 |
| Country of origin | Shanghai |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU 4BG1 |
| Rated power (kw/rpm) | 72.7/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | four-cylinder |
| Working form | Four-cylinder four-stroke turbocharged direct injection engine |
| Ground specific pressure (Kpa) | 43 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 92.7 |
| Rod digging force (kN) | 66.13 |
| Travel speed (km/h) | 5.5/3.5 |
| Total transport length (mm) | 7870 |
| Total transport width (mm) | 2570 |
| Total transport height (mm) | 2880 |
| Full cab height (mm) | 2740 |
| Minimum ground clearance (mm) | 425 |
| Minimum turning radius of front working device (mm) | 2490 |
| Back end turning radius (mm) | 2210 |
| Onboard width (mm) | 2490 |
| Total track length (mm) | 3665 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2930 |
| Maximum height at minimum turning radius (mm) | 6495 |
| Maximum digging radius (mm) | 8330 |
| Maximum digging depth (mm) | 5500 |
| Maximum excavation height (mm) | 8610 |
| Maximum unloading height (mm) | 6115 |
| Maximum vertical digging depth (mm) | 5085 |
