Product Description
Featuring a robust 4JJ1-XDJAG-01-C3 engine, this 2017 Sany SY115C excavator delivers 73 kW of power at 2000 rpm and a maximum torque of 365 N.m at 1600 rpm. With a working weight of 12,400 kg and a bucket capacity of 0.5 m³, it is designed for efficient and reliable performance. The hydraulic system provides a bucket digging force of 90.6 kN and a rod digging force of 57.2 kN, ensuring powerful and precise operations. Engineered with a ground specific pressure of 41.6 Kpa, the SY115C can handle challenging terrains, boasting a climbing ability of 70% (35°). This model also offers a travel speed of 5.5/3.5 km/h, making it highly maneuverable on various job sites. Made in China, the SY115C is built to withstand the demands of heavy construction, combining durability with advanced engineering.
| Specifications | Value |
|---|---|
| No. | 1000827 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 12400 |
| Bucket capacity (m³) | 0.5 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4JJ1-XDJAG-01-C3 |
| Rated power (kw/rpm) | 73/2000 |
| Maximum torque (N.m) | 365/1600 |
| Displacement (L) | 2.999 |
| Ground specific pressure (Kpa) | 41.6 |
| Rotation speed (rpm) | 13.06 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 90.6 |
| Rod digging force (kN) | 57.2 |
| Travel speed (km/h) | 5.5/3.5 |
| Fuel Tank (L) | 240 |
| Hydraulic Tank (L) | 150 |
| Engine Oil changes (L) | 15 |
| Total track length (mm) | 500 |
| Number of sprockets (single side) (each) | 1 |
| Number of wheels (single side) (each) | 1 |
| Number of track plates (single side) (PCS) | 41 |
