Product Description
Engineered with precision, this 2018 Sany SY125C excavator delivers robust performance through its Isuzu 4JJ1-XDJAG-01-C3 engine, generating 73kW at 2000rpm with 365N·m maximum torque. Operating at 12 tons working weight, the machine combines hydraulic efficiency with structural integrity—bucket digging force reaches 90.6kN while rod digging force achieves 57.2kN, ensuring consistent penetration across demanding applications.
Technical specifications demonstrate superior engineering standards:
- Maximum digging reach: 7735mm with 5190mm depth capability
- Bucket capacity range: 0.22-0.7m³ (standard 0.55m³)
- Ground specific pressure: 41.6kPa for reduced surface impact
- Rotation speed: 13.06rpm with 2880mm minimum turning radius
- 70% climbing ability on challenging terrain
- Water-cooled 2.999L displacement engine with 240L fuel capacity
Currently located in Luzhou, Sichuan, this China-manufactured excavator features a 500mm track plate width and 425mm ground clearance, providing stability and maneuverability for construction, excavation, and material handling operations. Complete with backhoe configuration and comprehensive hydraulic systems (150L tank capacity).
| Specifications | Value |
|---|---|
| No. | 1021529 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 12450 |
| Bucket capacity (m³) | 0.22-0.7 (0.55) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Isuzu 4JJ1-XDJAG-01-C3 |
| Rated power (kw/rpm) | 73/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 365/1600 |
| Displacement (L) | 2.999 |
| Ground specific pressure (Kpa) | 41.6 |
| Rotation speed (rpm) | 13.06 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 90.6 |
| Rod digging force (kN) | 57.2 |
| Travel speed (km/h) | 5.5/3.5 |
| Fuel Tank (L) | 240 |
| Hydraulic Tank (L) | 150 |
| Engine Oil changes (L) | 15 |
| Total transport length (mm) | 7280 |
| Total transport width (mm) | 2550 |
| Total transport height (mm) | 2890 |
| Full cab height (mm) | 2740 |
| Minimum ground clearance (mm) | 425 |
| Minimum turning radius of front working device (mm) | 2880 |
| Back end turning radius (mm) | 2205 |
| Onboard width (mm) | 2490 |
| Total track length (mm) | 3360 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2680 |
| Maximum height at minimum turning radius (mm) | 5905 |
| Number of sprockets (single side) (each) | 1 |
| Number of wheels (single side) (each) | 6 |
| Number of track plates (single side) (PCS) | 41 |
| Maximum digging radius (mm) | 7735 |
| Maximum digging depth (mm) | 5190 |
| Maximum excavation height (mm) | 7695 |
| Maximum unloading height (mm) | 5440 |
| Maximum vertical digging depth (mm) | 4720 |
