2018 Sany SY125C

1/9
Buy Sany SY125C Used Excavator / 1
Buy Sany SY125C Used Excavator / 2
Buy Sany SY125C Used Excavator / 3
Buy Sany SY125C Used Excavator / 4
Buy Sany SY125C Used Excavator / 5
Buy Sany SY125C Used Excavator / 6
Buy Sany SY125C Used Excavator / 7
Buy Sany SY125C Used Excavator / 8
Buy Sany SY125C Used Excavator / 9

Product Description

Sourced directly from Guangdong, China, this 2018 Sany SY125C is available now — no factory lead times, no waiting. Skip the queue and get a proven 12-ton excavator deployed to your site fast.

Powered by an Isuzu 4JJ1 engine producing 73 kW at 2000 rpm with 365 N·m of torque, this machine delivers reliable digging performance across demanding applications. A 0.55 m³ backhoe bucket paired with 90.6 kN bucket digging force and 57.2 kN rod digging force handles everything from trenching to bulk excavation.

  • Working weight: 12,450 kg | Ground pressure: 41.6 kPa
  • Max digging depth: 5,190 mm | Max digging radius: 7,735 mm
  • Max excavation height: 7,695 mm | Max unloading height: 5,440 mm
  • Travel speed: 5.5 / 3.5 km/h | Climbing ability: 70%
  • Fuel tank: 240 L | Hydraulic tank: 150 L
  • Transport dimensions: 7,280 × 2,550 × 2,890 mm

Water-cooled, Chinese-manufactured, and ready to work. With stock on the ground in Guangdong, logistics to Southeast Asia, the Middle East, or beyond move quickly. Inquire today for shipping timelines and pricing.

SpecificationsValue
No.1069388
Tonnage (tons)12
Working weight (kg)12450
Bucket capacity (m³)0.22-0.7 (0.55)
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeIsuzu 4JJ1-XDJAG-01-C3
Rated power (kw/rpm)73/2000
Cooling modewater-cooling
Maximum torque (N.m)365/1600
Displacement (L)2.999
Ground specific pressure (Kpa)41.6
Rotation speed (rpm)13.06
Climbing ability (%)70
Bucket digging force (kN)90.6
Rod digging force (kN)57.2
Travel speed (km/h)5.5/3.5
Fuel Tank (L)240
Hydraulic Tank (L)150
Engine Oil changes (L)15
Total transport length (mm)7280
Total transport width (mm)2550
Total transport height (mm)2890
Full cab height (mm)2740
Minimum ground clearance (mm)425
Minimum turning radius of front working device (mm)2880
Back end turning radius (mm)2205
Onboard width (mm)2490
Total track length (mm)3360
Track gauge (mm)1990
Track plate width (mm)500
Track ground length (mm)2680
Maximum height at minimum turning radius (mm)5905
Number of sprockets (single side) (each)1
Number of wheels (single side) (each)6
Number of track plates (single side) (PCS)41
Maximum digging radius (mm)7735
Maximum digging depth (mm)5190
Maximum excavation height (mm)7695
Maximum unloading height (mm)5440
Maximum vertical digging depth (mm)4720
see more

Overview

No.1069388

Brand Name:

Sany

Model Number:

SY125C

Year:

2018

Location:

Guangdong China

Pub Date
