Product Description
This 2018 Sany SY125C excavator, located in Guangdong, China, offers reliable performance for demanding applications. With complete documentation and excellent operational condition, this 12.5-ton class machine is ready for immediate deployment.
The unit demonstrates strong hydraulic performance across all systems, with responsive travel motors and exceptional cycle times. All major components—engine, hydraulics, and undercarriage—have been maintained to operational standards. The machine's speed and efficiency make it suitable for high-productivity environments including earthmoving, utility work, and general construction.
- Year: 2018
- Model: Sany SY125C
- Operating weight class: ~12.5 tons
- Complete documentation available
- Location: Guangdong, China
- Condition: Operational, inspection-ready
Competitively priced with verification available upon request. Suitable for contractors seeking proven mid-size excavator capacity with established OEM support.
| Specifications | Value |
|---|---|
| No. | 1081223 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 12450 |
| Bucket capacity (m³) | 0.22-0.7 (0.55) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Isuzu 4JJ1-XDJAG-01-C3 |
| Rated power (kw/rpm) | 73/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 365/1600 |
| Displacement (L) | 2.999 |
| Ground specific pressure (Kpa) | 41.6 |
| Rotation speed (rpm) | 13.06 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 90.6 |
| Rod digging force (kN) | 57.2 |
| Travel speed (km/h) | 5.5/3.5 |
| Fuel Tank (L) | 240 |
| Hydraulic Tank (L) | 150 |
| Engine Oil changes (L) | 15 |
| Total transport length (mm) | 7280 |
| Total transport width (mm) | 2550 |
| Total transport height (mm) | 2890 |
| Full cab height (mm) | 2740 |
| Minimum ground clearance (mm) | 425 |
| Minimum turning radius of front working device (mm) | 2880 |
| Back end turning radius (mm) | 2205 |
| Onboard width (mm) | 2490 |
| Total track length (mm) | 3360 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2680 |
| Maximum height at minimum turning radius (mm) | 5905 |
| Number of sprockets (single side) (each) | 1 |
| Number of wheels (single side) (each) | 6 |
| Number of track plates (single side) (PCS) | 41 |
| Maximum digging radius (mm) | 7735 |
| Maximum digging depth (mm) | 5190 |
| Maximum excavation height (mm) | 7695 |
| Maximum unloading height (mm) | 5440 |
| Maximum vertical digging depth (mm) | 4720 |
