2019 Sany SY125C

1/9
Buy Sany SY125C Used Excavator / 1
Buy Sany SY125C Used Excavator / 2
Buy Sany SY125C Used Excavator / 3
Buy Sany SY125C Used Excavator / 4
Buy Sany SY125C Used Excavator / 5
Buy Sany SY125C Used Excavator / 6
Buy Sany SY125C Used Excavator / 7
Buy Sany SY125C Used Excavator / 8
Buy Sany SY125C Used Excavator / 9

Product Description

The 2019 Sany SY125C crawler excavator represents a reliable mid-size solution for construction and earthmoving operations. This 12.5-ton class machine features Sany's proven hydraulic system and durable undercarriage design, delivering consistent performance across diverse jobsite conditions. Currently located in Zhejiang, China, this unit offers an economical entry point for contractors seeking dependable excavation equipment.

Key features include:

  • Operating weight approximately 12.5 tons with standard configuration
  • Fuel-efficient engine meeting emission standards
  • Reinforced boom and arm for extended service life
  • Spacious operator cabin with ergonomic controls
  • Competitive pricing for the 2019 model year

The SY125C is well-suited for general excavation, trenching, loading, and utility work. This used unit presents an opportunity to acquire proven Sany engineering at an attractive price point for regional and international buyers.

SpecificationsValue
No.1077128
Tonnage (tons)12
Working weight (kg)12450
Bucket capacity (m³)0.22-0.7 (0.55)
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeIsuzu 4JJ1-XDJAG-01-C3
Rated power (kw/rpm)73/2000
Cooling modewater-cooling
Maximum torque (N.m)365/1600
Displacement (L)2.999
Ground specific pressure (Kpa)41.6
Rotation speed (rpm)13.06
Climbing ability (%)70
Bucket digging force (kN)90.6
Rod digging force (kN)57.2
Travel speed (km/h)5.5/3.5
Fuel Tank (L)240
Hydraulic Tank (L)150
Engine Oil changes (L)15
Total transport length (mm)7280
Total transport width (mm)2550
Total transport height (mm)2890
Full cab height (mm)2740
Minimum ground clearance (mm)425
Minimum turning radius of front working device (mm)2880
Back end turning radius (mm)2205
Onboard width (mm)2490
Total track length (mm)3360
Track gauge (mm)1990
Track plate width (mm)500
Track ground length (mm)2680
Maximum height at minimum turning radius (mm)5905
Number of sprockets (single side) (each)1
Number of wheels (single side) (each)6
Number of track plates (single side) (PCS)41
Maximum digging radius (mm)7735
Maximum digging depth (mm)5190
Maximum excavation height (mm)7695
Maximum unloading height (mm)5440
Maximum vertical digging depth (mm)4720
see more

Overview

No.1077128

Brand Name:

Sany

Model Number:

SY125C

Year:

2019

Location:

Zhejiang China

Pub Date
