Product Description
Built in 2020, this Sany SY125C excavator delivers proven performance backed by one of China's most reliable heavy equipment manufacturers. Operating at 12 tons with a robust Isuzu 4JJ1 engine producing 73kW, this backhoe model combines dependable power with practical versatility. The 0.55m³ bucket capacity and 90.6kN digging force handle demanding excavation tasks efficiently, while the water-cooled engine ensures consistent operation in varied conditions.
Sany equipment holds exceptional value in the used market due to widespread parts availability and strong global dealer support. Critical specifications include:
- Maximum digging depth: 5,190mm with 7,735mm reach
- Travel speed: 5.5km/h for efficient jobsite mobility
- Fuel capacity: 240L minimizing downtime
- Transport dimensions: 7,280mm × 2,550mm × 2,890mm
Located in Luzhou, Sichuan, this machine represents a smart investment for contractors seeking dependable performance without premium pricing. Sany's reputation for durability and accessible service networks makes this SY125C an ideal choice for operations requiring consistent uptime and long-term resale potential.
| Specifications | Value |
|---|---|
| No. | 1026589 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 12450 |
| Bucket capacity (m³) | 0.22-0.7 (0.55) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Isuzu 4JJ1-XDJAG-01-C3 |
| Rated power (kw/rpm) | 73/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 365/1600 |
| Displacement (L) | 2.999 |
| Ground specific pressure (Kpa) | 41.6 |
| Rotation speed (rpm) | 13.06 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 90.6 |
| Rod digging force (kN) | 57.2 |
| Travel speed (km/h) | 5.5/3.5 |
| Fuel Tank (L) | 240 |
| Hydraulic Tank (L) | 150 |
| Engine Oil changes (L) | 15 |
| Total transport length (mm) | 7280 |
| Total transport width (mm) | 2550 |
| Total transport height (mm) | 2890 |
| Full cab height (mm) | 2740 |
| Minimum ground clearance (mm) | 425 |
| Minimum turning radius of front working device (mm) | 2880 |
| Back end turning radius (mm) | 2205 |
| Onboard width (mm) | 2490 |
| Total track length (mm) | 3360 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2680 |
| Maximum height at minimum turning radius (mm) | 5905 |
| Number of sprockets (single side) (each) | 1 |
| Number of wheels (single side) (each) | 6 |
| Number of track plates (single side) (PCS) | 41 |
| Maximum digging radius (mm) | 7735 |
| Maximum digging depth (mm) | 5190 |
| Maximum excavation height (mm) | 7695 |
| Maximum unloading height (mm) | 5440 |
| Maximum vertical digging depth (mm) | 4720 |
