Product Description
Expand your operational capacity with this 2016 Sany SY155C excavator, purpose-built for contractors managing multiple job sites simultaneously. Operating at 15 tons with a 14,100 kg working weight, this mid-size machine delivers consistent performance as a backup unit or primary fleet addition. The 0.55 m³ backhoe bucket handles high-volume earthmoving while the 73 kW rated power ensures reliable productivity across demanding applications.
Equipped with a proven 4JJ1-XDJAG-01-C3 engine generating 365 N·m maximum torque, this Beijing-based unit maintains steady output during extended shifts. The 240-liter fuel tank supports full-day operations, minimizing downtime for refueling. Strong digging forces—92.7 kN bucket and 66.13 kN arm—tackle compacted materials efficiently, while the 70% climbing ability navigates challenging terrain with confidence.
Key fleet-ready specifications include:
- 12 rpm rotation speed for precise positioning in confined spaces
- 5.5/3.5 km/h travel speeds for efficient site mobility
- 150-liter hydraulic tank with 500 mm track length for stability
- 43 kPa ground pressure reduces surface disruption
- Made in China with straightforward maintenance requir
| Specifications | Value |
|---|---|
| No. | 1044699 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 14100 |
| Bucket capacity (m³) | 0.55 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4JJ1-XDJAG-01-C3 |
| Rated power (kw/rpm) | 73/2000 |
| Maximum torque (N.m) | 365/160 |
| Displacement (L) | 2.999 |
| Ground specific pressure (Kpa) | 43 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 92.7 |
| Rod digging force (kN) | 66.13 |
| Travel speed (km/h) | 5.5/3.5 |
| Fuel Tank (L) | 240 |
| Hydraulic Tank (L) | 150 |
| Engine Oil changes (L) | 15 |
| Total track length (mm) | 500mm |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 44 |
