Product Description
Equipped with a 4JJ1-XDJAG-01-C3 engine, the Sany SY155C delivers 73 kW of power at 2000 rpm, ensuring robust performance. This 15-ton excavator, manufactured in China, boasts a working weight of 14,100 kg and a bucket capacity of 0.55 m³, making it ideal for demanding construction tasks. The hydraulic system is designed for efficiency, providing a maximum torque of 365 N.m at 160 rpm.
- Engine Type: 4JJ1-XDJAG-01-C3
- Rated Power: 73 kW/2000 rpm
- Maximum Torque: 365 N.m/160 rpm
- Bucket Capacity: 0.55 m³
- Travel Speed: 5.5/3.5 km/h
- Fuel Tank: 240 L
- Hydraulic Tank: 150 L
- Total Track Length: 500 mm
- Number of Sprockets (single side): 2
- Number of Wheels (single side): 8
- Number of Track Plates (single side): 44
With a ground specific pressure of 43 Kpa and a climbing ability of 70% (35°), this excavator handles rough terrain with ease. The Sany SY155C also features a backhoe bucket, delivering a digging force of 92.7 kN, and a rod digging force of 66.13 kN, ensuring powerful and precise excavation.
| Specifications | Value |
|---|---|
| No. | 1056992 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 14100 |
| Bucket capacity (m³) | 0.55 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4JJ1-XDJAG-01-C3 |
| Rated power (kw/rpm) | 73/2000 |
| Maximum torque (N.m) | 365/160 |
| Displacement (L) | 2.999 |
| Ground specific pressure (Kpa) | 43 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 92.7 |
| Rod digging force (kN) | 66.13 |
| Travel speed (km/h) | 5.5/3.5 |
| Fuel Tank (L) | 240 |
| Hydraulic Tank (L) | 150 |
| Engine Oil changes (L) | 15 |
| Total track length (mm) | 500mm |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 44 |
