Product Description
With a robust 4JJ1-XDJAG-01-C3 engine, the Sany SY155C delivers a rated power of 73 kW at 2000 rpm and a maximum torque of 365 N.m at 1600 rpm. This 15-ton excavator is equipped with advanced hydraulics, providing a bucket digging force of 92.7 kN and a rod digging force of 66.13 kN, ensuring efficient and powerful performance. The SY155C boasts a working weight of 14,100 kg and a bucket capacity of 0.55 m³, making it ideal for a variety of heavy-duty tasks. Engineered in China, this model features a ground specific pressure of 43 Kpa and a climbing ability of 70% (35°), enhancing its versatility and stability on challenging terrains. The machine's travel speed of 5.5/3.5 km/h, combined with a fuel tank capacity of 240 L, ensures extended operational hours and high productivity.
| Specifications | Value |
|---|---|
| No. | 1032435 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 14100 |
| Bucket capacity (m³) | 0.55 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4JJ1-XDJAG-01-C3 |
| Rated power (kw/rpm) | 73/2000 |
| Maximum torque (N.m) | 365/160 |
| Displacement (L) | 2.999 |
| Ground specific pressure (Kpa) | 43 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 92.7 |
| Rod digging force (kN) | 66.13 |
| Travel speed (km/h) | 5.5/3.5 |
| Fuel Tank (L) | 240 |
| Hydraulic Tank (L) | 150 |
| Engine Oil changes (L) | 15 |
| Total track length (mm) | 500mm |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 44 |
