Product Description
Built for immediate deployment on demanding job sites, this 2024 Sany SY155C excavator delivers 15 tons of proven digging performance. Powered by a robust 4JJ1-XDJAG-01-C3 engine generating 73kW at 2000 rpm, this machine tackles grading, trenching, and demolition work without hesitation. The 0.55m³ backhoe bucket combines with 92.7kN of bucket digging force to move material efficiently across construction, utility, and earthmoving applications.
- Working weight: 14,100kg with optimal stability for precision work
- Maximum torque: 365 N.m at 1600 rpm for consistent hydraulic power
- Climbing ability: 70% (35°) grade capability on steep terrain
- Travel speed: 5.5 km/h high range for rapid site repositioning
- Fuel capacity: 240L tank supports extended operating shifts
- Ground pressure: 43 kPa minimizes surface impact on sensitive sites
- Rotation speed: 12 rpm for productive cycle times
Currently located in Linyi, Shandong, this China-manufactured excavator arrives site-ready with traditional power systems proven across global markets. Contact Fair Trade Machinery for availability and shipping solutions.
| Specifications | Value |
|---|---|
| No. | 1022547 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 14100 |
| Bucket capacity (m³) | 0.55 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4JJ1-XDJAG-01-C3 |
| Rated power (kw/rpm) | 73/2000 |
| Maximum torque (N.m) | 365/160 |
| Displacement (L) | 2.999 |
| Ground specific pressure (Kpa) | 43 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 92.7 |
| Rod digging force (kN) | 66.13 |
| Travel speed (km/h) | 5.5/3.5 |
| Fuel Tank (L) | 240 |
| Hydraulic Tank (L) | 150 |
| Engine Oil changes (L) | 15 |
| Total track length (mm) | 500mm |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 44 |
