Product Description
Engineered for precision in confined workspaces, this 2021 Sany SY16C mini excavator delivers exceptional performance through its advanced Yanmar 3TNV70 engine. Rated at 10.3 kW at 2200 rpm with a maximum torque of 48.5–52.4 N·m, this 1.85-ton machine combines compact dimensions with robust digging capabilities. Hydraulic efficiency drives its 15.2 kN bucket digging force and 9.2 kN rod digging force, enabling operators to tackle demanding excavation tasks with confidence.
Technical specifications include:
- Maximum digging depth: 2,360 mm with 4,000 mm reach radius
- Variable bucket capacity: 0.02–0.06 m³ for versatile material handling
- Compact transport dimensions: 3,575 × 980/1,350 × 2,420 mm
- Superior climbing ability: 58% gradient capability
- Extended operational range: 23 L fuel tank capacity
- Minimal turning radius: 1,655 mm front, 920 mm rear
Currently located in Lishui, Zhejiang, this Chinese-manufactured excavator represents proven Sany engineering quality. Built for urban construction, landscaping, and utility installation projects requiring maneuverability without sacrificing power.
| Specifications | Value |
|---|---|
| No. | 1028758 |
| Tonnage (tons) | 1 |
| Working weight (kg) | 1850 |
| Bucket capacity (m³) | 0.02-0.06(0.04) |
| Country of origin | China |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 3TNV70 |
| Rated power (kw/rpm) | 10.3/2200 |
| Maximum torque (N.m) | 48.5~52.4 |
| Displacement (L) | 0.854 |
| Ground specific pressure (Kpa) | 29.1 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 58 |
| Bucket digging force (kN) | 15.2 |
| Rod digging force (kN) | 9.2 |
| Maximum tractive force (kN) | 15.5 |
| Travel speed (km/h) | 2.1~3.7 |
| Fuel Tank (L) | 23 |
| Hydraulic Tank (L) | 21 |
| Engine Oil changes (L) | 2 |
| Coolant (L) | 4.5 |
| Total transport length (mm) | 3575 |
| Total transport width (mm) | 980/1350 |
| Total transport height (mm) | 2420 |
| Counterweight ground clearance (mm) | 470 |
| Minimum ground clearance (mm) | 180 |
| Minimum turning radius of front working device (mm) | 1655 |
| Back end turning radius (mm) | 920 |
| Onboard width (mm) | 980 |
| Total track length (mm) | 1585 |
| Track gauge (mm) | 750/1220 |
| Track plate width (mm) | 230 |
| Total track width (mm) | 3575 |
| Track ground length (mm) | 1225 |
| Maximum height at minimum turning radius (mm) | 2745 |
| Number of wheels (single side) (each) | 3 |
| Maximum digging radius (mm) | 4000 |
| Maximum digging depth (mm) | 2360 |
| Maximum excavation height (mm) | 3665 |
| Maximum unloading height (mm) | 2635 |
| Maximum vertical digging depth (mm) | 2215 |
| Bulldozer lift or depth (mm) | 310/320 |
| Dodging plate width × height (mm) | 3575 x 270 |
| Maximum excavation radius of stop surface (mm) | 3900 |
