Product Description
Engineered for demanding excavation work, this 2017 Sany SY195C delivers 19-ton performance backed by proven Chinese manufacturing standards. Powered by a robust 4M50 engine generating 118 kW at 2000 rpm and 580 N·m maximum torque, this machine combines reliable traditional power with hydraulic efficiency. The operating weight of 20,900 kg provides exceptional stability while maintaining 47.3 kPa ground pressure for minimal surface impact.
Hydraulic power translates to impressive digging capability: 138 kN bucket force and 103 kN arm force handle tough materials with confidence. Operational reach extends to 10,280 mm maximum radius and 6,600 mm digging depth, supported by a 0.8-1.1 m³ bucket capacity. The 340-liter fuel tank and 239-liter hydraulic reservoir ensure extended work cycles without frequent refueling.
Currently located in Lianyungang, Jiangsu, this backhoe-configured excavator offers proven reliability for construction, mining, and earthmoving applications. Technical specifications include 70% grading ability, 5.4 km/h maximum travel speed, and 600 mm track width for versatile terrain performance.
| Specifications | Value |
|---|---|
| No. | 1032063 |
| Tonnage (tons) | 19 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.8~1.1(0.95) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Maximum torque (N.m) | 580/1600 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4060 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3260 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 45 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 9600 |
| Maximum vertical digging depth (mm) | 6255 |
