Product Description
Built for productivity, this 2018 Sany SY195C crawler excavator delivers 19-ton performance with immediate deployment capability. Powered by a reliable 4M50 engine producing 118 kW at 2000 rpm, this machine generates 138 kN bucket digging force and 103 kN arm force—sufficient power for excavation, grading, and demolition applications across demanding job sites.
- Operating weight: 20,900 kg with 0.8-1.1 m³ bucket capacity
- Maximum digging reach: 10,280 mm; digging depth: 6,600 mm
- 340L fuel tank and 239L hydraulic reservoir for extended shifts
- 70% gradeability and 47.3 kPa ground pressure for site versatility
- 600 mm track plates with 2,200 mm gauge for stable operation
- Currently located in Yichun, Jiangxi—ready for inspection
Transport dimensions of 9,680 × 2,800 × 3,440 mm facilitate straightforward logistics. Chinese-manufactured with proven Sany engineering, this excavator arrives work-ready with complete hydraulic systems and operational controls. Suitable for earthmoving contractors requiring dependable mid-size excavation capacity without extended lead times.
| Specifications | Value |
|---|---|
| No. | 1018920 |
| Tonnage (tons) | 19 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.8~1.1(0.95) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Maximum torque (N.m) | 580/1600 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4060 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3260 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 45 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 9600 |
| Maximum vertical digging depth (mm) | 6255 |
