Product Description
Built for high-output earthmoving and excavation work, this 2019 Sany SY195C delivers 19-ton performance with proven reliability. Powered by a 118 kW (158 HP) 4M50 engine generating 580 N·m of torque, this machine handles demanding digging, trenching, and site preparation tasks without hesitation. Currently located in Changzhou, Jiangsu, it's ready for immediate deployment on construction sites, infrastructure projects, or demolition operations.
Key specifications include:
- Operating weight: 20,900 kg with 0.8–1.1 m³ bucket capacity
- Maximum digging depth: 6,600 mm; digging radius: 10,280 mm
- Bucket digging force: 138 kN; stick digging force: 103 kN
- 340 L fuel tank for extended work shifts
- 70% gradeability (35°) for challenging terrain
- 600 mm track plates providing 47.3 kPa ground pressure
Engineered by Sany with robust hydraulics and a durable undercarriage, this excavator combines power, reach, and stability for productive daily operation. Transport dimensions of 9,680 × 2,800 × 3,440 mm facilitate efficient mobilization between job sites.
| Specifications | Value |
|---|---|
| No. | 1021385 |
| Tonnage (tons) | 19 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.8~1.1(0.95) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Maximum torque (N.m) | 580/1600 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4060 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3260 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 45 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 9600 |
| Maximum vertical digging depth (mm) | 6255 |
