Product Description
Proven performance meets long-term value in this 2019 Sany SY195C excavator, currently located in Lianyungang, Jiangsu. Operating at 19 tons with a robust 118kW engine delivering 580 N·m of maximum torque, this machine combines serious digging force (138kN bucket, 103kN arm) with the reliability that has made Sany China's leading heavy equipment manufacturer. With a maximum digging reach of 10,280mm and depth capabilities to 6,600mm, it handles demanding excavation tasks while maintaining fuel efficiency through its 340L tank and proven 4M50 engine technology.
Choosing a used Sany means investing in smart economics. Parts availability throughout China and expanding global networks ensures minimal downtime, while Sany's strong resale values protect your capital investment. The SY195C's 0.8-1.1m³ bucket capacity and 5.4km/h travel speed deliver productivity that competing brands struggle to match at this price point.
- Working weight: 20,900kg with superior stability
- Hydraulic system: 239L tank for consistent performance
- Transport dimensions: 9,680mm × 2,800mm × 3,440mm
- Climbing ability: 70% (35°) grade capability
- Backed by China's largest equipment manufacturer
| Specifications | Value |
|---|---|
| No. | 1027353 |
| Tonnage (tons) | 19 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.8~1.1(0.95) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Maximum torque (N.m) | 580/1600 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4060 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3260 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 45 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 9600 |
| Maximum vertical digging depth (mm) | 6255 |
