Product Description
Available now in Guizhou, this 2019 Sany SY195C excavator eliminates factory lead times and accelerates your project timeline. Powered by a robust 4M50 engine delivering 118 kW at 2000 rpm, this 19-ton workhorse combines proven performance with immediate deployment capability. Skip months of waiting—secure ready-to-work equipment that ships directly to your site from central China.
- Working Weight: 20,900 kg with operational stability for demanding applications
- Bucket Capacity: 0.8–1.1 m³ (standard 0.95 m³) for versatile material handling
- Maximum Digging Reach: 10,280 mm with 6,600 mm digging depth
- Digging Force: 138 kN bucket force, 103 kN arm force for tough ground conditions
- Climbing Ability: 70% (35°) grade capability with 440 mm ground clearance
- Fuel Capacity: 340 L tank supports extended operation between refueling
Positioned in Guizhou for rapid logistics throughout Southwest China and export markets, this machine offers immediate ROI without procurement delays. Specifications verified, documentation complete, ready for inspection and fast deployment.
| Specifications | Value |
|---|---|
| No. | 1027657 |
| Tonnage (tons) | 19 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.8~1.1(0.95) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Maximum torque (N.m) | 580/1600 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4060 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3260 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 45 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 9600 |
| Maximum vertical digging depth (mm) | 6255 |
