Product Description
Engineered with precision, this 2019 Sany SY195C excavator delivers exceptional performance through its robust 4M50 engine generating 118kW at 2000 rpm with 580 N·m maximum torque. Advanced hydraulic systems provide 138kN bucket digging force and 103kN rod digging force, ensuring superior excavation capabilities across demanding jobsites.
Built on Sany's proven engineering foundation, this 19-ton machine combines a generous 0.95m³ bucket capacity with impressive reach specifications—10,280mm maximum digging radius and 6,600mm maximum digging depth. Operating efficiency remains paramount with 340L fuel capacity and optimized 47.3kPa ground pressure distribution.
- Powerful 4.9L displacement engine with traditional power configuration
- Comprehensive hydraulic performance: 239L tank capacity
- Versatile mobility: 70% climbing ability and 5.4km/h travel speed
- Compact transport dimensions: 9,680mm length, 2,800mm width
- Professional-grade construction from established Chinese manufacturing
Located in Zhejiang Shaoxing, this SY195C represents Sany's commitment to reliable construction equipment engineering.
| Specifications | Value |
|---|---|
| No. | 991829 |
| Tonnage (tons) | 19 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.8~1.1(0.95) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Maximum torque (N.m) | 580/1600 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4060 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3260 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 45 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 9600 |
| Maximum vertical digging depth (mm) | 6255 |
