Product Description
Built for demanding construction sites, this 19-ton Sany SY195C delivers reliable performance with its robust 4M50 engine producing 118kW of power. Operating at 20,900kg working weight, this machine handles heavy-duty excavation tasks with precision and efficiency.
Key operational capabilities include:
- Maximum digging depth of 6.6 meters for deep foundation work
- 10.28-meter digging radius covering extensive work areas
- 138kN bucket digging force for tough soil conditions
- 0.95m³ bucket capacity optimized for material handling
- 70% climbing ability on steep terrain
Equipped with a 340-liter fuel tank and 239-liter hydraulic system, this excavator maintains productivity throughout extended work shifts. The compact 2.8-meter transport width ensures easy site mobility while the 440mm ground clearance provides stability on uneven surfaces. Ready for immediate deployment on grading, trenching, and demolition projects across Shanghai's construction landscape.
| Specifications | Value |
|---|---|
| No. | 992747 |
| Tonnage (tons) | 19 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.8~1.1(0.95) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Maximum torque (N.m) | 580/1600 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4060 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3260 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 45 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 9600 |
| Maximum vertical digging depth (mm) | 6255 |
