Product Description
With a robust 20-ton working weight and a powerful SANY D06S2 engine, this 2012 Sany SY195C-9 excavator is site-ready for immediate deployment. Capable of delivering 135 kN of bucket digging force, it excels in challenging digging, grading, and demolition tasks. Equipped with a six-cylinder, four-stroke turbocharged direct injection engine, the machine provides a rated power of 114 kW at 2050 rpm, ensuring consistent performance.
- Bucket capacity: 0.83 m³ (optional 0.7~1.0 m³)
- Travel speed: 5.4/3.3 km/h
- Maximum digging depth: 6410 mm
- Ground specific pressure: 47.3 Kpa
- Manufactured in Shanghai, China
Featuring a full cab height of 2990 mm and a minimum ground clearance of 440 mm, this excavator is designed for stability and maneuverability. Its 2200 mm track gauge and 600 mm (800/700 optional) track plate width provide excellent traction and support, making it ideal for various construction sites. Ready to work, the SY195C-9 is a reliable and efficient choice for your heavy-duty needs.
| Specifications | Value |
|---|---|
| No. | 1020723 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 20700 |
| Bucket capacity (m³) | 0.83 (optional 0.7~1.0) |
| Country of origin | Shanghai |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | SANY D06S2 |
| Rated power (kw/rpm) | 114/2050 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6-cylinder |
| Working form | Six-cylinder four-stroke turbocharged direct injection engine |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 135 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9560 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 2955 |
| Full cab height (mm) | 2990 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3755 |
| Back end turning radius (mm) | 2890 |
| Onboard width (mm) | 2710 |
| Total track length (mm) | 4060 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 (800/700 optional) |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3260 |
| Maximum digging radius (mm) | 9740 |
| Maximum digging depth (mm) | 6410 |
| Maximum excavation height (mm) | 9410 |
| Maximum unloading height (mm) | 6490 |
| Maximum vertical digging depth (mm) | 5790 |
