Product Description
Built for demanding excavation work, this 2016 Sany SY195C-9 delivers 20-ton performance with operator-focused engineering. Powered by a Sany D06S2 6-cylinder turbocharged engine producing 114 kW at 2050 rpm, this machine combines reliable power with precise hydraulic control. Operators benefit from exceptional stability, supported by a 2200mm track gauge and optimized 47.3 kPa ground pressure that maintains balance across varied terrain.
Cabin design prioritizes all-day comfort and visibility, with commanding sightlines to the 9740mm maximum digging radius and 6410mm digging depth. Responsive joystick controls manage 135 kN bucket digging force and 109 kN arm force with accuracy, while the 11 rpm swing speed enables efficient load cycles. The spacious cab reduces operator fatigue during extended shifts, complemented by smooth travel speeds up to 5.4 km/h.
Currently located in Hunan Changsha, this Chinese-manufactured excavator features a 0.83 m³ bucket capacity and proven water-cooled engine technology. With 440mm ground clearance and 70% gradeability, it handles challenging jobsite conditions while maintaining productive output.
| Specifications | Value |
|---|---|
| No. | 1016331 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 20700 |
| Bucket capacity (m³) | 0.83 (optional 0.7~1.0) |
| Country of origin | Shanghai |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | SANY D06S2 |
| Rated power (kw/rpm) | 114/2050 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6-cylinder |
| Working form | Six-cylinder four-stroke turbocharged direct injection engine |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 135 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9560 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 2955 |
| Full cab height (mm) | 2990 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3755 |
| Back end turning radius (mm) | 2890 |
| Onboard width (mm) | 2710 |
| Total track length (mm) | 4060 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 (800/700 optional) |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3260 |
| Maximum digging radius (mm) | 9740 |
| Maximum digging depth (mm) | 6410 |
| Maximum excavation height (mm) | 9410 |
| Maximum unloading height (mm) | 6490 |
| Maximum vertical digging depth (mm) | 5790 |
