Product Description
Designed for operators who demand precision and control, this 2024 Sany SY200C delivers 20-ton performance with exceptional stability and responsiveness. Powered by a robust 118 kW engine at 2000 rpm, the machine offers smooth hydraulic action and confident digging force—138 kN bucket force and 103 kN arm force—making it ideal for medium to heavy excavation tasks across diverse jobsites.
Operators benefit from excellent cabin visibility and intuitive controls that reduce fatigue during extended shifts. With a ground pressure of just 47.4 kPa, the SY200C maintains stability on soft terrain while delivering a 70% (35°) climbing ability for challenging grades. Dual travel speeds of 5.4/3.4 km/h and an 11 rpm rotation speed ensure efficient positioning and cycle times.
- Operating weight: 21,500 kg with 0.8–1.0 m³ bucket capacity
- Superior visibility and ergonomic operator station
- Low ground pressure for enhanced stability
- Currently located in Wuxi, Jiangsu—ready for international delivery
| Specifications | Value |
|---|---|
| No. | 1031748 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.8~1.0 (1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.4 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.4 |
