Product Description
Proven in the field since 2015, this Sany SY205C excavator exemplifies rugged reliability for demanding earthmoving operations. Operating at 20 tons with a robust working weight of 21,500 kg, this Chinese-manufactured workhorse delivers consistent performance through its 118 kW rated power at 2000 rpm. Built to withstand challenging conditions, it features a maximum digging depth of 6,600 mm and impressive bucket digging force of 138 kN, making it ideal for heavy excavation tasks.
- Bucket Capacity: 0.9-1.1 m³ (standard 1.0 m³)
- Maximum Digging Reach: 10,280 mm
- Maximum Digging Height: 9,600 mm
- Climbing Capability: 70% (35°) grade
- Travel Speed: 5.4/3.3 km/h
- Transport Dimensions: 9,680 × 2,980 × 3,440 mm
Currently located in Changzhou, Jiangsu, this dependable machine has demonstrated its durability over nearly a decade of service. With traditional power systems and straightforward maintenance requirements, it represents a cost-effective solution for contractors seeking a proven performer without compromise.
| Specifications | Value |
|---|---|
| No. | 1027903 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
