Product Description
Built for precision and all-day productivity, this 2015 Sany SY205C delivers the control and visibility operators demand on demanding job sites. Operating at 20 tons with a robust 118kW engine, this excavator combines responsive hydraulics with a thoughtfully designed cabin that reduces fatigue during extended shifts. The backhoe configuration provides exceptional reach—up to 10,280mm maximum digging radius and 6,600mm digging depth—while maintaining stable performance across varied terrain.
Operators benefit from clear sightlines and intuitive controls that make repetitive tasks more efficient. The machine's 47.3kPa ground pressure distributes weight effectively, minimizing ground disturbance while the 70% climbing ability tackles steep grades confidently. With 138kN bucket digging force and 109kN arm digging force, this China-manufactured unit handles tough material without hesitation.
- Spacious cab with 3,075mm height for improved visibility
- Compact 2,900mm rear turning radius for confined spaces
- Dual travel speeds (5.4/3.3 km/h) for site flexibility
- 0.9-1.1m³ bucket capacity for balanced cycle times
- Currently located in Hunan, ready for global deployment
| Specifications | Value |
|---|---|
| No. | 1029128 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
