Product Description
Powered by a robust 118kW engine at 2000rpm, this 2016 Sany SY205C delivers exceptional digging performance with 138kN bucket force and 109kN arm force. Operating at 20 tons with a 21,500kg working weight, this excavator represents proven Chinese engineering designed for demanding excavation work. The hydraulic system drives a 0.9-1.1m³ backhoe bucket through a maximum digging depth of 6,600mm and reach of 10,280mm, providing versatile site coverage.
Built on a stable 2,380mm track gauge with 600mm-wide plates, the SY205C maintains just 47.3kPa ground pressure while achieving 70% (35°) climbing capability. Compact transport dimensions of 9,680mm length enable efficient relocation between jobsites. The 11rpm rotation speed and 3,730mm minimum front turning radius ensure precise positioning in confined areas.
Key Technical Specifications:
- Rated Power: 118kW at 2000rpm
- Bucket Digging Force: 138kN
- Maximum Digging Reach: 10,280mm
- Maximum Digging Depth: 6,600mm
- Operating Weight: 21,500kg
- Location: Guangzhou, Guangdong, China
| Specifications | Value |
|---|---|
| No. | 1021962 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
