Product Description
Built for demanding jobsites, this 2016 Sany SY205C delivers reliable 20-ton performance with operator-centered engineering. Powered by a 118 kW engine at 2000 rpm, this excavator combines substantial digging force—138 kN bucket force and 109 kN arm force—with exceptional maneuverability for medium to heavy-duty excavation, trenching, and loading applications.
Operators benefit from enhanced visibility and ergonomic cabin design standard to Sany's mid-2010s engineering. The 3075 mm full cab height provides generous headroom, while the compact 2900 mm rear turning radius enables precise positioning in confined spaces. With 440 mm ground clearance and 70% climbing ability, this machine maintains stability across challenging terrain.
- Maximum digging reach: 10,280 mm with 6,600 mm depth capability
- 0.9-1.1 m³ bucket capacity for versatile material handling
- Dual travel speeds (5.4/3.3 km/h) for efficient site mobility
- 600 mm track plates and 47.3 kPa ground pressure minimize surface damage
- Currently located in Guizhou, China—ready for global export
Factory-direct from China, this backhoe-equipped excavator offers proven Sany durability for contractors requiring depen
| Specifications | Value |
|---|---|
| No. | 1024243 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
