Product Description
With a working weight of 21,500 kg and a bucket capacity ranging from 0.9 to 1.1 m³, the Sany SY205C excavator, manufactured in 2019, stands as a robust and reliable choice for your construction needs. Built to last, this machine has proven its durability and efficiency on numerous job sites. Featuring a rated power of 118 kW at 2000 rpm, it delivers consistent performance with a ground specific pressure of 47.3 Kpa, ensuring stability and versatility. The SY205C boasts a climbing ability of 70% or 35°, making it suitable for challenging terrains. Its impressive digging forces—138 kN for the bucket and 109 kN for the rod—coupled with a travel speed of up to 5.4 km/h, make it a formidable workhorse. Located in 浙江杭州, this excavator is ready to tackle your toughest projects with reliability and strength.
| Specifications | Value |
|---|---|
| No. | 1020823 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
