Product Description
With a robust 20-ton capacity and a working weight of 21,500 kg, the Sany SY205C excavator from 2019 offers reliable performance and durability. Made in China, this model is known for its high resale value and easy parts availability, making it a smart investment for any construction fleet. Powered by a traditional engine with a rated power of 118 kW at 2000 rpm, it delivers consistent and efficient operation. The SY205C features a backhoe bucket with a capacity of 0.9 to 1.1 m³, providing versatility on various job sites. Its climbing ability of 70% or 35° and a travel speed of up to 5.4 km/h ensure it can handle challenging terrains. Located in Guangxi, this excavator is ready to meet your heavy-duty needs with reliability and strength.
- Bucket digging force: 138 kN
- Maximum digging depth: 6600 mm
- Track gauge: 2380 mm
- Ground specific pressure: 47.3 Kpa
| Specifications | Value |
|---|---|
| No. | 1022738 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
